BTS442E2E3062A

power switch, TO220-5, BTS442E2E3062A, 63 V, ±5.0mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.08~2.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.08~2.30

PartNumber:: BTS442E2E3062A

Brand:: Infineon Technologies AG - Infineon | Pack: SMD | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sally Wei's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-17

From Other Seller

Part Number:BTS442E2E3062A
US $1.08 - 2.30
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BTS442E2E3062A is a smart highside high current power switch. N channel vertical power FET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, integrated in Smart SIPMOS chip on chip technology. The BTS442E2E3062A Provides embedded protective functions.Applications of the BTS442E2E3062A power switch with current sense diagnostic; feedback for 12 v and 24 DC grounded loads; most suitable for loads with high inrush current like lamps and motors; all types of resistive and inductive loads; replaces electromechanical relays, fuses and discrete circuits.

Parametrics

BTS442E2E3062A absolute maximum ratings: (1)Supply voltage (overvoltage protection see page 4) Vbb: 63 V; (2)Load dump protection VLoadDump = UA + Vs, UA = 13.5 V RI= 2 Ω, RL= 1.1 Ω, td= 200 ms, IN= low or high VLoad dump3): 80 V; (3)Load current IL: self-limited A; (5)Operating temperature range Tj: -40 ,+150 ℃; (6)Storage temperature range Tstg: -55 ,+150 ℃; (7)Power dissipation (DC), TC ≦ 25 ℃ Ptot: 167 W; (8)Inductive load switch-off energy dissipation, single pulse Vbb = 12V, Tj,start = 150℃, TC = 150℃ const, IL = 20 A, ZL = 7.5 mH, 0 Ω, EAS: 2.1 J; (9)Electrostatic discharge capability (ESD) Human Body Model : 2 kV; (10)Current through input pin (DC) IIN: ±5.0mA; (11)Current through current sense status pin (DC) IIS: ±5.0mA.
