Product Summary
The MUR3040PT is a switch mode power rectifier. This state of the art device is designed for use in switching power supplies, inverters and as free wheeling diodes.
Parametrics
MUR3040PT absolute maximum ratings: (1)Peak Repetitive Reverse Voltage, VRRM: 400V; (2)Working Peak Reverse Voltage, VRWM: 400V; (3)DC Blocking Voltage, VR: 400V; (4)Average Rectified Forward Current (Rated VR), IF(AV): 15A @ TC = 150℃; (5)Average Rectified Forward Current (Rated VR), IF(AV): 30A @ TC = 150℃; (6)Peak Rectified Forward Current, Per Leg (Rated VR, Square Wave, 20 kHz), IFRM: 30A @ TC = 150℃; (7)Nonrepetitive Peak Surge Current, IFSM: 200A; (8)Operating Junction and Storage Temperature, TJ, Tstg: -65 to +175℃
Features
MUR3040PT features: (1)Ultrafast 35 and 60 Nanosecond Recovery Time; (2)175℃ Operating Junction Temperature; (3)High Voltage Capability to 600V; (4)Low Forward Drop; (5)Low Leakage Specified @ 150℃ Case Temperature; (6)Current Derating Specified @ Both Case and Ambient Temperatures; (7)Epoxy Meets UL 94 V-0 @ 0.125 in; (8)High Temperature Glass Passivated Junction; (9)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MUR3040PT |
Fairchild Semiconductor |
Rectifiers TO-218AC Ultra Fast |
Data Sheet |
Negotiable |
|
||||||||||||
 |
MUR3040PT, |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
MUR3040PTG |
ON Semiconductor |
Rectifiers 400V 30A UltraFast |
Data Sheet |
|
|
||||||||||||
